WeightechUSA WT3000P Digital Weight Indicator, Serial RS-232, NTEP Certified

SKU
20080
$358.00
  • 01 WT3000P Digital Weight Indicator, NTEP certified, ABS IP68 washdown enclosure;
  • 01 Internal rechargeable 6V / 4.5 Ah battery (up to 15 hours runtime per charge);
  • 01 110/220V AC power supply (auto-voltage detection on latest revisions);
  • Built-in full-duplex RS232 port; Bluetooth interface available as an option.
  • Capacity: NTEP Class III, up to 10,000 divisions
  • Compatible with platform, bench, livestock, cattle chute, and truck scales.

Operation Manual  |  Datasheet

OR
  • Description
  • Additional Information
  • 01 / 06NTEP-certified weight indicator

    One indicator. Almost every industrial scale you support.

    The WT3000P is built for scale builders, system integrators, and end-users who need a single legal-for-trade indicator that adapts to whatever weighing application is in front of them. Platform scales, bench scales, livestock chutes, truck scales — the WT3000P drives them all, with the IP68 ABS housing that survives the washdown bays where lesser indicators give up.

    10,000div
    NTEP Class III, legal-for-trade
    IP68
    ABS washdown enclosure
    8cells
    up to 8 × 350 Ω (or 16 × 700 Ω)
    55mm
    backlit LCD digit height (2.15 in)
    02 / 06Built around what scale builders need

    Four reasons the WT3000P keeps showing up in installations.

    NTEP

    Class III, 10,000 divisions

    NTEP certified for legal-for-trade applications. Internal resolution of 1/500,000, non-linearity of 0.01% FS, and 0.3 µV/d cell sensitivity — the precision floor for commercial weighing.

    IP68

    ABS washdown housing

    Sealed ABS plastic enclosure rated IP68 — submersible-grade dust and water protection. Designed for food processing lines, meat plants, livestock barns, and any scale that gets hosed down at end of shift.

    RS232

    Built-in full-duplex serial

    A full-duplex RS232 port standard on every unit, with 16 selectable transmission formats and a complete serial command set. Optional Bluetooth module for wireless integration. Address support for RS-485 multi-drop networks.

    2-YR

    Two-year limited warranty

    Backed by a two-year limited warranty and supported directly from Davie, FL. Built by Berman Weighing Technology, distributed and serviced by WeightechUSA.

    03 / 06Where the WT3000P fits

    Four scale categories, one indicator.

    The WT3000P drives up to eight 350 Ω load cells (or sixteen 700 Ω cells) with a 5 VDC excitation, which covers the vast majority of industrial scale builds across four common categories.

    01

    Platform & floor scales

    Standard 4-cell pallet scales, drum scales, and stainless steel washdown platforms. The IP68 housing pairs cleanly with food-grade scale decks; the 16-format serial output handles every PC or PLC the platform feeds.

    4-cell builds, standard
    02

    Bench & checkweigh scales

    Use the built-in check-weigh function (high/low limits with audible beep) to turn any single-point load cell scale into a go/no-go checkweigher. Piece counting mode supported when filling, counting, or pre-packaging.

    Hi/Lo + piece counting built in
    03

    Livestock & cattle chute

    Built-in animal weighing modes (HOLD 4 and HOLD 5) capture stable readings from moving animals — adjustable averaging from 1 to 64 samples, with configurable error tolerance from 1% to 100%. The IP68 enclosure handles barn and pasture conditions.

    Animal-weighing modes built in
    04

    Truck scales

    Eight 350 Ω cells across two summing junction boxes is the standard pit-scale or above-ground truck-scale build. NTEP legal-for-trade certification is required for commercial truck weighing — the WT3000P delivers it out of the box.

    8-cell truck-scale ready
    Cabling note: The WT3000P uses 6-wire load cell connection (sense + signal + excitation, both polarities, plus ground) for long cable runs without voltage-drop drift. 4-wire load cells can be jumpered at the indicator. Maximum recommended cable run depends on cell impedance and total cell count.
    04 / 06Connectivity & integration

    Sends weight data to wherever the system needs it.

    The built-in full-duplex RS232 port and 16 selectable transmission formats cover practically every downstream device a scale builder pairs an indicator with — PLCs over Modbus-ASCII, PC software over serial, network gateways, and direct connection to ticket printers and remote displays. Optional Bluetooth gives you wireless data capture to a tablet, phone, or laptop on the floor.

    Print accumulating ticket formats with date, time, gross, tare, and net to Epson TM-U295 or Zebra TLP2844 / CG420 thermal printers — useful for buyer transactions on truck and livestock scales. Pair with the DR-WT75, DR-WT125, or DR-WT200 remote displays for visible-from-the-aisle readouts. Foot switch input lets the operator zero, tare, or print hands-free.

    • +RS232 full-duplex (built in)
    • +Bluetooth interface (optional)
    • +16 transmission formats
    • +Ticket printing (Epson / Zebra)
    • +Remote display drive (DR-WT series)
    • +Foot switch input
    • +RS-485 address support
    05 / 06Technical data

    WT3000P full specifications.

    Approval / precisionNTEP Class III, up to 10,000 divisions
    Internal resolution1 / 500,000
    Non-linearity0.01% FS
    Cell sensitivity0.3 µV / d
    Input signal range−1 to +14 mV/V
    Input zero range−1 to +5 mV/V
    Maximum load cells8 × 350 Ω (or 16 × 700 Ω)
    Load cell excitation5 VDC
    Load cell connection6-wire (4-wire jumperable)
    CommunicationRS232 full-duplex (built in); Bluetooth (optional)
    Power supply110 / 220 VAC, 50/60 Hz (auto on latest revisions)
    Internal battery6 V / 4.5 Ah rechargeable
    Battery autonomyUp to 15 hours; 8 hour recharge
    Power consumption150 mA
    Operating temperature0 °C to 40 °C (32 °F to 104 °F)
    Display6-digit LCD with backlight, 55 mm (2.15 in) digit height
    Measurement unitslb, kg, oz, g
    HousingABS plastic, IP68 rated
    Warranty2 years limited
    ManufacturerBerman Weighing Technology
    06 / 06Procurement and integration FAQ

    Common questions from scale builders and integrators.

    Is the WT3000P NTEP certified for legal-for-trade?

    Yes. The WT3000P is NTEP certified at Class III, up to 10,000 divisions. That covers commercial truck weighing, livestock sales, and any application where the weight reading is the basis for a transaction.

    How many load cells can I drive from one indicator?

    Up to 8 cells at 350 Ω in parallel, or up to 16 cells at 700 Ω — both configurations present the same effective impedance to the 5 VDC excitation circuit. For larger arrays, use a summing junction box and treat the J-box output as a single signal source.

    Which printers and remote displays are compatible?

    Direct serial integration with Epson TM-U295 and TM-U220, Zebra TLP2844 and CG420, and Elgin L42 thermal printers. Remote displays from the Weightech DR-WT75 / DR-WT125 / DR-WT200 line connect directly via the same RS232 port with a dedicated transmission format.

    Can I get the WT3000P with Bluetooth?

    Yes. The Bluetooth interface is an optional factory-installed module — contact sales with your application and we'll confirm pricing and lead time for the Bluetooth-equipped configuration.

    How long does the internal battery last?

    Up to 15 hours of runtime per charge from the 6 V / 4.5 Ah internal battery. Recharge takes about 8 hours from the 110/220 VAC supply. For installations without consistent power, dedicated 12 VDC or solar configurations are available — ask sales.

    What's the difference between the WT3000P and the WT3000-IR-AG cattle scale kit?

    The WT3000P is the stand-alone indicator in an ABS IP68 housing — for scale builders integrating it into platform, bench, livestock, or truck scales. The WT3000-IR-AG is a complete pre-mounted livestock kit (indicator + two weigh bars + power supplies + IP65 carry case) tuned for chute-side and pasture use with a 40-hour extended battery and integrated Bluetooth.

    Does the WT3000P support animal weighing?

    Yes. Two dedicated animal-weighing modes (HOLD 4 and HOLD 5) capture stable readings from moving livestock with configurable averaging from 1 to 64 samples and adjustable error tolerance from 1% to 100%. Pairs cleanly with low-profile weigh bars, alley scales, and chute floor scales.

    Talk to a WeightechUSA specialist.

    Need a specific configuration, volume pricing, or help matching the WT3000P to an existing scale build? Our team supports system integrators and OEM scale manufacturers directly from Davie, FL.

    Email Sales Call +1 (954) 666-0877 × 305
