Dinamica Generale IN-FIELD Feeding Monitoring DG400 Weight Indicator
- Description
- Additional Information
- 01 / 06DG400 feeding monitor
Farm feeding indicator for mixer and feeder wagons.
The DG400 is a Dinamica Generale indicator for mixer and feeder wagons, bovine nutrition, rationing systems, and feeding applications on small and medium farms.
The product data calls out IP68 protection, multilingual interface, diagnostics, overload control, total/partial and net/gross modes, WiNET port for accessories, and optional Modbus / CAN J1939 protocols.
IP68ProtectionWiNETAccessory portNet/GrossWorking modesCANJ1939Protocol option02 / 06Application fitA practical feeding-scale indicator for livestock operations.
01Mixer/feed wagons
Weight monitoring for feed mixing and distribution.
feeding02Retrofit replacement
Direct replacement positioning for Digistar and Avery Weigh-Tronix indicators.
replacement03Accessory expansion
WiNET port supports plug-and-play accessory connection.
accessories03 / 06What matters on the installationFocused on field usability.
MODESModes
Total/partial and net/gross working modes.
HOUSINGProtection
IP68 protection for demanding farm environments.
WINETAccessories
WiNET port for plug-and-play accessory connection.
COMMSProtocols
Modbus and CAN J1939 available on request.
04 / 06Integration notesDG400 keeps feeding operation simple and expandable.
Use the DG400 when the job needs a field indicator with accessory support and clear feeding workflow rather than complex recipe management.
- Overload control
- Total/partial and net/gross modes
- WiNET accessory port
- All models of load cells can be connected
- Modbus and CAN J1939 protocols on request
05 / 06Technical dataDG400 specifications.
Protection IP68 Modes Total/partial, net/gross Accessory port WiNET plug-and-play Protocols Modbus / CAN J1939 on request Application Mixer and feeder machinery 06 / 06Part number and FAQConfirm the exact configuration before ordering.
Product Order code Dinamica Generale IN-FIELD Feeding Monitoring DG400 Weight Indicator 22792 Can WeightechUSA confirm fit before ordering?
Yes. Send the scale type, load-cell count, environment, power, and communication requirement and we will confirm the configuration.
What should I verify before replacing an existing indicator?
Confirm enclosure style, power supply, scale input, load-cell impedance, printer or PLC connections, and whether legal-for-trade approval is required.
Talk to a WeightechUSA specialist.
Send the feeder brand, load-cell details, and accessory requirements and we will confirm DG400 fit.
Email SalesCall +1 (954) 666-0877 × 305 Protection class IP68 Material Specific Nylon with Glass Fiber V0 Resolution 1, 2, 5, 10, 20, 50 Display 45 mm (1.77 inches) Input power supply 9.5 – 32 VDC Internal Battery No Operating temp range -30 / +65°C (-22 /+150°F) (-45°C / -49°F on request) Weight of equipment UNIVERSAL CASE:2,5 kg (5.5 lbs) - SLIM CASE:1,9 kg (4.2 lbs) Manufacturer Dinamica Generale Display Visibility 15 m and more (50 fit) Accuracy < +/- 0.015% f.s.
