WeightechUSA PDCC Load Cell Digitizer Board (Board Only), RS-232 / RS-485 / Ethernet, 5.6-15 VDC

SKU
20090
$572.00
  • PDCC load cell digitizer — board only (factory code 503329), no enclosure
  • Supply 5.6–15 VDC; 8 × 350 Ω or 16 × 700 Ω load cells
  • RS-232, RS-485 (half/full-duplex) and Ethernet 10/100 Mbps
  • 1/1,000,000 resolution, 0.01% F.S. uncertainty, up to 4.0 mV/V
  • 6 isolated TTL outputs and 2 isolated TTL inputs
  • Cabinet versions (plastic/DIN-rail, IP67 stainless steel) available on request

Datasheet

OR
  • Description
  • Additional Information
  • 01 / 06WeightechUSA PDCC digitizer board

    High-performance load cell digitizer for checkweighers.

    The WeightechUSA PDCC (SKU 20090) is a load cell signal digitizer for industrial processes that demand high precision and speed. It is configured by software and is fully parameterizable through the HBM standard communication protocol, over a serial or Ethernet interface. SKU 20090 is the bare circuit board only (factory code 503329, serial port boot version), supplied without an enclosure.

    1/1,000,000
    A/D converter resolution
    4.0mV/V
    Max. measurement range
    0.01% F.S.
    Uncertainty of a stable weight
    5.6–15VDC
    Supply voltage
    02 / 06Features

    Built for stable, configurable weight readings.

    01

    Fully parameterizable

    Adjustable to the user's needs, and configurable remotely without proprietary software, using the HBM standard communication protocol.

    02

    Protected calibration

    Calibration is protected against unauthorized changes by hardware, and non-volatile memory prevents configuration loss.

    03

    Advanced signal processing

    Adjustable digital filters and a high-resolution conversion of the load cell signal give more stable readings and reduce interference.

    04

    Isolated digital I/O

    Six isolated TTL outputs and two isolated TTL inputs for integration with other industrial devices and systems. The manual also describes automatic and weight-gain / weight-loss dosing.

    03 / 06Versions and protection

    Board only — no enclosure.

    SKU 20090 is the bare PDCC board, supplied without an enclosure and with no degree of protection. The PDCC is also made in a plastic cabinet with a DIN-rail bracket and in an IP67 stainless steel cabinet, available on request.

    BOARD

    Digitizer board (board only)

    Circuit board only, 83 × 134 × 20 mm, factory code 503329. No degree of protection stated. The manual recommends a metallic enclosure for hostile environments and notes that the board has no electrostatic discharge protection.

    INSTALL

    Install it in an enclosure

    Mount the board in a suitable metallic enclosure that matches your environment, and handle it with ESD precautions.

    04 / 06Interfaces and load cells

    Connections.

    01

    Serial and Ethernet

    RS-232, RS-485 (half- and full-duplex) and Ethernet TCP/IP (RJ45). Serial speed 1200–115200 bps, Ethernet 10/100 Mbps. The active interface is selected in software; the manual states that only one can be used at a time.

    02

    Load cells

    Up to 8 load cells of 350 Ω, or up to 16 load cells of 700 Ω in parallel (minimum equivalent resistance 40 Ω). 5 V load cell supply, six-terminal load cell connector (J4: excitation, sense, signal).

    03

    Digital I/O

    Terminal J6: six isolated TTL outputs (OUT 1–6) and two isolated TTL inputs (IN 1–2).

    05 / 06Technical data

    PDCC specifications.

    Brand / modelWeightechUSA PDCC
    SKU20090
    TypeLoad cell digitizer board for checkweighers
    Supply voltage5.6-15 VDC (terminal J7)
    Load cell supply voltage5 V
    Maximum number of load cells8 x 350 ohm, or 16 x 700 ohm in parallel (min. 40 ohm equivalent)
    Maximum measurement range4.0 mV/V
    A/D converter resolution1/1,000,000
    Measurement uncertainty (stable weight)0.01 % F.S.
    Signal conversion range (low-pass filter)0-200 Hz
    Communication interfacesRS-232, RS-485 (half- and full-duplex), Ethernet TCP/IP (RJ45)
    Serial interface speed1200-115200 bps
    Ethernet interface speed10/100 Mbps
    Digital I/O6 isolated TTL outputs, 2 isolated TTL inputs
    Communication protocolHBM standard protocol
    Operating temperature0 to +40 C
    Circuit board dimensions (L x W x H)83 x 134 x 20 mm
    Degree of protection, single plateNot rated
    Other versions (on request)Plastic cabinet + DIN-rail bracket; stainless steel cabinet IP67
    06 / 06Part numbers and FAQ

    Factory part numbers.

    SKU 20090 is the board only, factory code 503329 (serial port boot version). The Ethernet port boot version of the board is code 504481, available on request.

    ProductOrder code
    PDCC digitizer board (board only), serial port boot version — store SKU 20090503329

    Is the PDCC waterproof?

    SKU 20090 is the bare board and has no stated degree of protection. Install it in a suitable (metallic) enclosure. A stainless steel cabinet version (IP67) is available on request.

    How many load cells can it drive?

    Up to 8 load cells of 350 ohm, or up to 16 load cells of 700 ohm connected in parallel, with a minimum equivalent resistance of 40 ohm.

    Which supply voltage does it need?

    5.6 to 15 VDC at terminal J7.
