The Zemic HM9C-N10-50K-9.3B is the 50000 lb capacity Zemic HM9C, a hermetically sealed dual shear beam load cell, optimized for mechanical shock load resistance, for onboard, truck and rail scales and other heavy weighing devices such as silos, manufactured in nickel-plated alloy steel with IP68 ingress protection.
| Manufacturer | Zemic |
| Manufacturer part number | HM9C-N10-50K-9.3B |
| Capacity | 50000 lb |
| Approval | — |
| Rated output | 3.0 ± 0.008 mV/V |
| Dimensions | 260.4 × Ø76.2 mm |
| Material | Nickel-plated alloy steel, hermetically sealed |
| Protection | IP68 (EN 60529) |
| Signal | Analog |
| Input resistance | 700 ± 7 Ω |
| Output resistance | 703 ± 4 Ω |
| Insulation resistance | ≥ 5000 MΩ @ 50 VDC |
| Zero balance | ≤ ±1.0 %FS |
| Compensated temperature | −10 to +40 °C |
| Operating temperature | −35 to +65 °C |
| Recommended excitation | 5 to 12 VDC |
| Maximum excitation | 18 VDC |
| Safe overload | 150 %FS |
| Ultimate overload | 300 %FS |
| Wiring | Excitation (+) red, Signal (−) white, Excitation (−) black, Signal (+) green |
| Accuracy class | N10 |
| Maximum verification intervals (nmax) | 10000 |
| Cable | 4-conductor shielded polyurethane, AWG 22, Ø8 mm, shield not connected to the element |
| Mounting | 2 × Ø26.9 mm through holes |
| Product | Order code |
|---|---|
| Zemic HM9C 50000 lb Double-Ended Shear Beam Load Cell (HM9C-N10-50K-9.3B) | 24215 |
Use the SKU and manufacturer part number above as the order code, then confirm wiring, signal, and environment with WeightechUSA before ordering.
Yes. Send photos of the installed cell, the label, mounting dimensions, cable colors, capacity, and the scale application.
Send the old load-cell label, capacity, dimensions, cable details, and application. We will confirm the manufacturer part number and fit.
Email SalesView DatasheetCall +1 (954) 666-0877 × 305| Capacity | Manufacturer part number | SKU | Approval | Price |
|---|---|---|---|---|
| 20000 lb | HM9C-N10-20K-9.3B | 24212 | — | $527.00 |
| 30000 lb | HM9C-N10-30K-9.3B | 24213 | — | $670.00 |
| 40000 lb | HM9C-N10-40K-9.3B | 24214 | — | $670.00 |
| 60000 lb | HM9C-N10-60K-9.3B | 24216 | — | $670.00 |

| Signal | Analog |
|---|---|
| Protection class | IP68 |
| Material | Nickel-Plated Alloy Steel |
| Compensated temp range | −10 to +40 °C |
| Input impedance | 700 ± 7 Ω |
| Insulation resistance | ≥ 5000 MΩ @ 50 VDC |
| Internal Battery | -- |
| Maximum excitation | 18 VDC |
| Maximum number of intervals | 10000 nLC |
| Maximum safe overload | 150 %FS |
| Operating temp range | −35 to +65 °C |
| Output impedance | 703 ± 4 Ω |
| Rated capacity | 50000 lb |
| Rated output | 3.0 ± 0.008 mV/V |
| Recommended excitation | 5 ~ 12 VDC |
| Ultimate central overload | 300 %FS |
| Zero balance | ≤ ±1.0 %FS |
| Manufacturer | Zemic |
| Accuracy | N10 |
| Number of Wires | 4 wires |
| Manufacturer's Part Number | HM9C-N10-50K-9.3B |
| Short name | HM9C-50K lb N10 Double-Ended Shear Beam Load Cell |
| Hero chips | IP68; Nickel-Plated Alloy Steel; Analog signal; 4 wires |
